What Affects the Service Life of Dust - Removal Filter Bags?

AddTimes:2026-05-12   Visits:1358

What factors affect the service life of dust - removal filter bags? Now, let's follow the editor of Mingkai Environmental Protection to find out!

1. Impact of High Temperature on Filter Bags

Use the approved continuous and short-term operating limits for the selected filter media, finish and process conditions. Record the temperature of normal operation, the peak temperature and the duration of excursions. Heat, moisture and gas chemistry can act together to weaken a fabric, so the bag grade must be checked against the actual duty rather than a single temperature threshold.

2. Impact of Low - Temperature Dewing on Filter Bags

When the boiler is in the initial start - up stage in winter or under low - load operation, the temperature of the flue gas is relatively low. Coupled with factors such as local air leakage, the local temperature is likely to be lower than the dew point temperature, resulting in dew formation. It will react with SO₂ in the flue gas to form acid mist, causing corrosion to the filter bag, reducing the characteristic indicators of the filter bag. In severe cases, large - area caking of the filter bag may occur. Once reaching a certain weight, it will cause the filter bag to fall off, seriously affecting the service life of the filter bag. In addition, in northern regions in winter, if the insulation is not good, ash accumulation on the inner wall of the ash hopper is likely to occur, causing ash blocking in the ash hopper. Moreover, during the initial start - up stage, the ash hopper is under negative pressure, and the steam generated by the water removal of ash will also be brought into the ash hopper, which may easily cause ash accumulation in the ash hopper, leading to serious consequences.

3. Impact of Filtration Airflow Rate on Filter Bags

The filtration airflow rate is an important factor determining the performance of the dust collector. If it is too high, the pressure loss will be too large, causing the filter bag to clog and wear out rapidly. Generally speaking, for dusty gas with high dust concentration, fine particle size, and high abrasiveness, a lower filtration airflow rate should be selected; otherwise, a higher one can be chosen. If the filtration airflow rate of the bag - type dust collector is too large, the resistance will increase, the porosity of the dust layer will decrease under pressure, and the airflow will break through at the weak points of the dust - removal filter bag, resulting in the "punch - through" phenomenon. The higher the filtration airflow rate, the more serious the "punch - through" phenomenon of the dust - removal filter bag. Therefore, the filtration airflow rate should be well - controlled.

4. Impact of Aggressive Ash Cleaning on Filter Bags

Cleaning method, pressure, duration and frequency should follow the collector design and the media requirements. Review pressure-drop trends, dust release and the condition of the bag and cage together. Rough contact surfaces, loose fit or repeated movement between the bag and cage can contribute to abrasion. The effect of a cleaning system cannot be judged from its pressure category alone.

5. Impact of Air Inlet Mode on Filter Bags

The selected air inlet mode will also directly affect the service life of the filter bag. It is necessary to ensure that the pressure differences of several chambers are relatively balanced as much as possible. Once the pressure difference of one chamber increases, most of the flue gas will enter other chambers to balance the pressure difference. However, if there is a leak in one chamber of the filter bag, the resistance of the flue gas passing through the filter bag will decrease, and the pressure difference of this chamber will drop. Then, most of the flue gas will enter this chamber. While increasing the flow rate, it also intensifies the wear of the filter bag.


The above are several factors affecting the service life of dust - removal filter bags. Hope it helps you.

Fabric filter bag beside its cylindrical wire support cage and flanged connection


For material selection, browse our dust collector filter bags and review the effect of flue gas conditions. Send the collector details and the failed bag specification to Mingkai when requesting a replacement review.
